D8168N-24V-10mm 16.2W/1M
D8168N-24V-10mm 16.2W/1M
• Mini cutting unit of 5.95mm.
• Consistent illumination with no dark ends when used in aluminium profiles, perfect for joinery and stair application.
• High lumen and high density strip.
• COLORS Brand Light source.
![D8168N_Main image.png](https://static.wixstatic.com/media/9f6792_747a8ea946e34c1db7b71b95bac757a2~mv2.png/v1/fill/w_49,h_41,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/9f6792_747a8ea946e34c1db7b71b95bac757a2~mv2.png)
D8168N_Main image.png
![D8168N_1.png](https://static.wixstatic.com/media/9f6792_ed515cc8d680439e9e21d02cf801fca7~mv2.png/v1/fill/w_58,h_39,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/9f6792_ed515cc8d680439e9e21d02cf801fca7~mv2.png)
![D8168N_6.png](https://static.wixstatic.com/media/9f6792_d5799ca882fd41beaa606bc2bbceec2e~mv2.png/v1/fill/w_58,h_39,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/9f6792_d5799ca882fd41beaa606bc2bbceec2e~mv2.png)
![D8168N_Main image.png](https://static.wixstatic.com/media/9f6792_747a8ea946e34c1db7b71b95bac757a2~mv2.png/v1/fill/w_49,h_41,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/9f6792_747a8ea946e34c1db7b71b95bac757a2~mv2.png)
D8168N_Main image.png
1/6
Size
10 x 1.5mm x Length = Custom
Cutting Unit
5.95mm
Input Voltage
24VDC
Typical Power
16.2W/1M
No. of LEDS
168 PCS/M
CRI
90
Colour Consistency
SDCM <2 | 1 BIN
IP Rating
IP20 | IP65 | IP67
Lifetime
L70 > 60,000 hours
Continuous Max Run
5M
Compliance
EMC
Warranty
3 years
